Drawing: Chapter 12

CHAPTER 12

Unmanned Aerial Vehicles and Cruise Missiles

This chapter shows examples of unmanned aerial vehicles (UAVs) and cruise missiles. UAVs will perform a variety of missions; reconnaissance, surveillance, intelligence, targeting, and acquisition (RISTA). Cruise missiles are like artillery, which detonate at proximity, on command, or on impact.

There are many more UAVs than can be listed here. For this manual, UAVs were grouped together based on similarities and roles. One, and in some cases, two, UAVs were selected from each group to be represented in this manual.

For each aircraft, there are line drawings, general data, WEFT descriptions, user countries, photographs, and aircraft manufacturer information. The following illustration shows early warning, observation, and reconnaissance aircraft WEFT description features. Line drawings are not to scale.

WEFT Descripton Features

Chapter 12 Aircraft List

Apache CWS D-4 NPU Pioneer
AS-4 Kitchen DR-3 Reys Predator
AS-15 Kent Model 324 Raven
Banshee BTT-3 Model 410 Scout
Brevel Mirach 26 Shmel-1 Yak-061
BQM-34 Firebee II Mirach 100 Taifun
C-101 MK-105 Flash Tomahawk AGM-86
Crecerelle MK-106 HIT
